INTEGRIX iX8 1-8X28 34mm FFP LPVO Scope, A1 MOA

SKU

iX801FA1

Coming Soon

THE CULMINATION OF INTEGRATED & INTELLIGENT OPTICAL DESIGN & MANUFACTURING.

INTEGRIX is pinnacle performance. Years of experience were brought to the forefront through expert development and evaluation, countless testing, and meticulous manufacturing. German and Japanese glass lenses used exclusively in every INTEGRIX optic are individually centration tested, multi-coated for glare, reflection, and scratch resistance, and upon assembly are inspected for concentricity as a whole.

THE END RESULT? Optimized image quality with over 92% light transmission, edge-to-edge sharpness, minute distortion, and high contrast resolution.

$1,399.97

Out of stock

Notify me when the price drops

Notify me when this product is in stock

Details

Individually Centration Tested German and Japanese Glass, Concentric Tested Post Assembly
Multi-Coated Lenses for Glare, Reflection, and Scratch Resistance
Low Aberration Optimized Image Quality with Over a 92% Light Transmittance
Edge to Edge Sharpness, High Contrast, and High-Resolution Standard
Reliable Adverse Temperature and Environmental Performance with -40° to 160° Fahrenheit Operational Range and IPX7 Waterproof Rating
Rated, at Minimum, for .338 LAPUA Magnum
Red and Green Reticle Illumination with 10 Brightness Intensity Settings
12 Hour Automatic Shutoff
Intuitive Lockable and Zero Resettable Windage and Elevation Turrets, Serrated and Oversized for Glove Use
Serrated Power Ring and Rear Adjustable Eyepiece Diopter
Make Transitioning Across Magnification Range Effortless with Included Oversized Throw Lever

ETCHED GLASS RANGE-ESTIMATING A1 MOA RETICLE

At 1X, a quick-to-acquire T-Dot enclosed within a 68 MOA segmented circle makes close up work, quick and to the point, functioning similarly to a dot sight. At higher magnifications the reticle opens up to provide users with a crisp 1 MOA center dot, range estimation out to 600 yards, and hash marks up to 60 MOA vertically for holdover and 30 MOA horizontally left and right in 2 MOA increments.

RETICLE BREAKDOWN

UNIT	A	B	C	D	E	F	G	H	I	J	K
MOA	60	20	8	4	2	34	4	1	10	2	0.25

UNIT	L	M	N	Q
inch @ 100 yards			18
inch @ 200 yards		18
inch @ 300 yards	18			18

ACCESSORIES INCLUDED

Throw Lever
Flip-open Lens Caps
Hex Wrench 2 mm
Hex Wrench 1.5 mm
CR2032 Battery
Cleaning Cloth
User Manual

RESOURCES

More Information
Length (in)	10.9
Maintube Diameter (mm/in)	34 mm
Objective Length (in)	1.06
Objective Length (mm)	27
Eyepiece Length (in)	3.39
Eyepiece Length (mm)	86
Front Mounting Space (in)	2.17
Front Mounting Space (mm)	55
Rear Mounting Space (in)	2.64
Rear Mounting Space (mm)	67
Outer Objective Bell Diameter (in)	1.38
Outer Eyepiece Diameter (in)	1.81
Outer Eyepiece Diameter (mm)	46
922R Compliant	No
Warranty	Lifetime
Materials	6061-T6 Aluminum
Color(s)	Black
Parts Included	Lens Cover, User Manual
Focal Plane	FFP (First Focal Plane)
Reticle	A1 MOA
Reticle Type	Etched Glass
Reticle Illumination	Yes
Reticle Color(s)	Red and Green
Brightness Mode(s)	Manual
Waterproof Rating	IPX7
Operating Temperature High (⁰F)	160
Operating Temperature Low (⁰F)	-40
Operating Temperature High (⁰C)	70
Operating Temperature Low (⁰C)	-40
Ballistic Drop Compensation	No
Range Estimation	Yes
Battery Loading	Left Side Turret
Battery Type	CR2032 3V
Click Value @ 100 Yards (MOA)	1/2
Windage Adjustment Left (MOA)	25
Windage Adjustment Right (MOA)	25
Windage Adjustment Per Revolution (MOA)	50
Elevation Adjustment Up (MOA)	60
Elevation Adjustment Down (MOA)	40
Magnification Max.	8
Magnification Min.	1
Angular FOV Low Mag. (Degrees)	21.8
Angular FOV High Mag. (Degrees)	2.7
Linear FOV Low Mag. (ft @ 100 yds)	115.5
Linear FOV High Mag. (ft @ 100 yds)	14.1
Linear FOV Low Mag. (m @ 100 m)	38.5
Linear FOV High Mag. (m @ 100 m)	4.7
Light Transmission (%)	92%
Eye Relief High Mag. (in)	3.5
Eye Relief Low Mag. (in)	3.7
Eye Relief High Mag. (mm)	90
Eye Relief Low Mag. (mm)	94
Parallax Control	Fixed
Parallax Preset (yds)	100
Parallax Preset (m)	91.4
Exit Pupil High Mag. (mm)	3.5
Exit Pupil Low Mag. (mm)	11
Objective Lens Diameter (mm)	28
Diopter Adjustment	+3D ~ +2D
Diopter Type	Friction Secured
Caliber Rating	.338 Lapua Magnum
Weight (oz)	25.3
Weight (g)	716

Dimensions

Eyepiece Length (in)	3.39
Eyepiece Length (mm)	86
Front Mounting Space (in)	2.17
Front Mounting Space (mm)	55
Length (in)	10.9
Maintube Diameter (mm/in)	34 mm
Objective Length (in)	1.06
Objective Length (mm)	27
Outer Eyepiece Diameter (in)	1.81
Outer Eyepiece Diameter (mm)	46
Outer Objective Bell Diameter (in)	1.38
Rear Mounting Space (in)	2.64
Rear Mounting Space (mm)	67

LEAPERS LIFETIME WARRANTY

Leapers, Inc. warrants that all products conform to published specifications and are free from defects in material and workmanship. Leapers, Inc. will repair or replace, at our discretion, a defective product for the duration of the product’s lifespan. Verification through an RA number is required. In the event of a product being discontinued, credit in the amount of the product’s MSRP may be offered.
